Hex Socket Plugs for NPT Threads

HSPN


Plastic NPT Bolt with Hex Socket
Hex Socket Plugs for NPT Threads

HSPN–Media

Hex Socket Plugs for NPT Threads Hexagon Stopping Plug for NTP Threads Plastic NPT Blanking Plugs Hexagon Blanking Plugs Hex Plugs for National Pipe Threads Plastic NPT Bolt with Hex Socket Plastic Hex Socket Plugs for NPT Threads Hex Socket Threaded Plastic Plug Caps Polypropylene Plastic Hex Socket Plugs for NPT Threads
  • Material: PP (Polypropylene)
  • Stocked Material: PP (Red)
  • Designed to Protect Threads from Dirt, Dust and Moisture During Low-Pressure Testing and In-Plant Handling

Size Chart Plastic NPT Blanking Plugs

HSPN Size Chart

Table View
List View
Part # Description To Fit NPT Inside Diameter
in
mm
 Inside Length
in
mm
 Length
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
HSPN0250 Hex Socket Plugs for NPT Threads - HEX SOCKET PLUG FOR 1/4-18 NPT THRDS 1/4 - 18
0.260
6.6
0.310
7.9
0.500
12.7
 3500 700 70
HSPN0375 Polypropylene Plastic Hex Socket Plugs for NPT Threads - HEX SOCKET PLUG FOR 3/8-18 NPT THRDS 3/8 - 18
0.330
8.4
0.380
9.7
0.566
14.4
 4000 800 80
HSPN0500 Hex Socket Threaded Plastic Plug Caps - HEX SOCKET PLUG FOR 1/2-14 NPT THRDS 1/2 - 14
0.390
9.9
0.380
9.7
0.566
14.4
 5000 1000 100
HSPN0750 Plastic Hex Socket Plugs for NPT Threads - HEX SOCKET PLUG FOR 3/4-14 NPT THRDS 3/4 - 14
0.570
14.5
0.470
11.9
0.610
15.5
 2000 400 40
HSPN1000 Plastic NPT Bolt with Hex Socket - HEX SOCKET PLUG FOR 1-11-1/2 NPT THRDS 1 - 11-1/2
0.640
16.3
0.590
15.0
0.740
18.8
 1600 320 32
Part # Description To Fit NPT Inside Diameter
in
mm
 Inside Length
in
mm
 Length
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.



Hex Socket Plugs for NPT Threads - Information

MOCAP Hex Socket Plugs are designed for use on NPT threads and fittings. The Socket design allows for threads to be protected during low-pressure testing and in-house processing or handling, however these are not intended for permanent applications.
Protects threaded components from moisture, dust and damage during production, shipping and storage, and can also be used as masking during painting and plating. The HSPN Series Threaded Plugs are molded in Red polypropylene plastic and sized to fit NPT threads from 1/4-18 thru 1-11-1/2.

MOCAP stocks Hex Socket Plugs for NPT Threads in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.







RoHS


Diagram
