Paper Straight Caps

MPSC


Inexpensive Paper Straight Caps
Paper Straight Caps

MPSC–Media

Paper Straight Caps Paper Masking Products Environmentally friendly paper caps Paper Protection Caps Paper Straight Caps Inexpensive Paper Straight Caps High-Temperature Paper Straight End Cap Straight Paper Cap Paper End Caps Paper Straight Caps
  • Material: Paper
  • Environmentally Friendly and Economical Masking Solution
  • Does Not Promote Condensation

Size Chart Environmentally friendly paper caps

MPSC Size Chart

Table View
List View
Part # Description To Fit MALE NPT To Fit Tube Size To Fit STD Thread To Fit Flared Tube Fitting To Fit METRIC Thread To Fit BSP Inside Diameter
in
mm
Inside Length
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
MPSC001 Paper Straight Caps - STRAIGHT CAP, PAPER - TAN 5/16 1/4, 5/16 1/8 M8, M9 G1/8
0.303
7.7
0.370
9.4
22000 1000 100
MPSC003 Paper End Caps - STRAIGHT CAP, PAPER TAN 1/8 3/8 3/8, 7/16 3/16 M10,M11 G1/8
0.354
9.0
0.374
9.5
25000 1000 100
MPSC004 Straight Paper Cap - STRAIGHT CAP, PAPER - TAN 1/8 7/16 7/16, 1/2 1/4 M11,M12
0.417
10.6
0.453
11.5
18000 1000 100
MPSC005 High-Temperature Paper Straight End Cap - STRAIGHT CAP, PAPER - TAN 1/4 1/2 1/2, 9/16 5/16 M14,M15 G1/4
0.469
11.9
0.512
13.0
12500 1000 100
MPSC006 Inexpensive Paper Straight Caps - STRAIGHT CAP, PAPER - TAN 3/8 5/8 5/8, 11/16 3/8 M16, M17,M18 G3/8
0.598
15.2
0.528
13.4
8000 1000 100
MPSC007 Paper Straight Caps - STRAIGHT CAP, PAPER - TAN 1/2 3/4 3/4, 13/16 1/2 M20 G1/2
0.717
18.2
0.673
17.1
8500 1000 100
MPSC009 Paper Protection Caps - STRAIGHT CAP, PAPER - TAN 7/8 7/8, 15/16 5/8 M22 G5/8
0.811
20.6
0.823
20.9
5500 1000 100
MPSC010 Environmentally friendly paper caps - STRAIGHT CAP, PAPER - TAN 3/4 1 1, 1-1/16 3/4 M25, M26, M27 G3/4
0.957
24.3
0.862
21.9
4000 800 80
MPSC011 Paper Masking Products - STRAIGHT CAP, PAPER - TAN 1 1-5/16 1-1/4, 1-5/16 1 M32, M33 G1
1.205
30.6
0.996
25.3
3400 680 68
MPSC013 Paper Straight Caps - STRAIGHT CAP, PAPER - TAN 1-1/4 1-5/8 1-9/16, 1-5/8 1-1/4 M40, M42 G1-1/4
1.543
39.2
1.197
30.4
1800 360 36
MPSC016 Paper End Caps - STRAIGHT CAP, PAPER - TAN 1-7/8 1-7/8 1-1/2 M48 G1-1/2
1.827
46.4
0.913
23.2
1800 360 36
Part # Description To Fit MALE NPT To Fit Tube Size To Fit STD Thread To Fit Flared Tube Fitting To Fit METRIC Thread To Fit BSP Inside Diameter
in
mm
Inside Length
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.

NOTE:
  • Part dimensions are typical from a measured lot. Individual pieces may vary.
  • Due to the material, this product may have minor dimensional variation due to changes in relative humidity.
  • Flange concentricity may vary.
  • Due to paper's natural structure, the product may be oblong in free state. This will generally aid in the product's retention capability.




Paper Straight Caps - Information

MOCAP Paper Straight Caps are an environmentally friendly and economical masking solution. Made of recyclable paper, these straight paper caps do not promote condensation. These closures will withstand up to 400°F(204°C), making them ideal for low-to-high temperature applications.

Note: Due to the material, these Straight Paper Caps may have minor dimensional variation due to changes in relative humidity.
Our MPSC Series Caps are manufactured in tan paper and sized to fit 1/8 thru 1-1/2 flared tube fittings or 5/16 thru 1-7/8 tube OD's

MOCAP stocks Paper Straight Caps in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
