Threaded Plastic Plugs for Flared JIC Fittings

FJP


Male Flared JIC Plastic Plugs
Threaded Plastic Plugs for Flared JIC Fittings

FJP–Media

Threaded Plastic Plugs for Flared JIC Fittings Threaded Plastic Cap for Flared JIC Fittings Threaded Plastic Plugs for Flared JIC Fittings Threaded Plastic Flared JIC Plugs Joint Industry Council Fittings Male Flared JIC Plastic Plugs Flared JIC Plug Caps (Polypropylene Plastic) Plastic Bolt for Flared JIC Fittings
  • Material: LDPE (Low Density Polyethylene)
  • Stocked Material: LDPE (Red)
  • Designed for flared JIC Fittings and to Seal 37° Flare Fittings without Gaskets

Size Chart Threaded Plastic Plugs for Flared JIC Fittings

FJP Size Chart

Table View
List View
Part # Description Tube Size
in
mm
 To Fit STD Thread JIC Fitting Dash Size Length
in
mm
 Flange OD
in
mm
 Flange Thickness
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
FJP20 Threaded Plastic Plugs for Flared JIC Fittings - PLUG FOR 5/16-24 FLARED JIC FTNGOR 1/8 TUBE
0.125
3.2
 5/16 - 24 2
0.440
11.2
0.440
11.2
0.180
4.6
 5000 1000 100
FJP30 Threaded Plastic Plugs for Flared JIC Fittings - PLUG FOR 3/8-24 FLARED JIC FTNGOR 3/6 TUBE
0.188
4.8
 3/8 - 24 3
0.460
11.7
0.500
12.7
0.180
4.6
 5000 1000 100
FJP40 Plastic Bolt for Flared JIC Fittings - PLUG FOR 7/16-20 FLARED JIC FTNGOR 1/4 TUBE
0.250
6.4
 7/16 - 20 4
0.530
13.5
0.620
15.7
0.190
4.8
 5000 1000 100
FJP50 Flared JIC Plug Caps (Polypropylene Plastic) - PLUG FOR 1/2-20 FLARED JIC FTNGOR 5/16 TUBE
0.313
7.9
 1/2 - 20 5
0.530
13.5
0.680
17.3
0.250
6.4
 5000 1000 100
FJP60 Male Flared JIC Plastic Plugs - PLUG FOR 9/16-18 FLARED JIC FTNGOR 3/8 TUBE
0.375
9.5
 9/16 - 18 6
0.500
12.7
0.810
20.6
0.250
6.4
 5000 1000 100
FJP65 Joint Industry Council Fittings - PLUG FOR 5/8-18 FLARED JIC FTNGOR 3/8 TUBE
-
-
 5/8 - 18
0.590
15.0
0.810
20.6
0.250
6.4
 5000 1000 100
FJP80 Threaded Plastic Flared JIC Plugs - PLUG FOR 3/4-16 FLARED JIC FTNGOR 1/2 TUBE
0.500
12.7
 3/4 - 16 8
0.750
19.1
0.940
23.9
0.250
6.4
 2000 400 40
FJP100 Threaded Plastic Plugs for Flared JIC Fittings - PLUG FOR 7/8-14 FLARED JIC FTNGOR 5/8 TUBE
0.625
15.9
 7/8 - 14 10
0.870
22.1
1.060
26.9
0.250
6.4
 2500 500 50
FJP110 Threaded Plastic Cap for Flared JIC Fittings - PLUG FOR 1-1/16-12 FLARED JIC FTNG
0.750
19.1
 1-1/16 - 12 12
0.860
21.8
1.410
35.8
0.250
6.4
 1500 300 30
FJP140 Threaded Plastic Plugs for Flared JIC Fittings - PLUG FOR 1-1/16-14 FLARED JIC FTNG
0.750
19.1
 1-1/16 - 14 12
0.860
21.8
1.410
35.8
0.250
6.4
 2000 400 40
FJP120 Threaded Plastic Plugs for Flared JIC Fittings - PLUG FOR 1-1/16-14 FLARED JIC FTNGOR 3/4 TUBE
0.750
19.1
 1-1/16 - 14 12
1.120
28.4
1.310
33.3
0.250
6.4
 1200 240 24
FJP150 Plastic Bolt for Flared JIC Fittings - PLUG FOR 1-3/16-12 FLARED JIC FTNG
0.875
22.2
 1-3/16 - 12 14
0.930
23.6
1.500
38.1
0.250
6.4
 1200 240 24
FJP160 Flared JIC Plug Caps (Polypropylene Plastic) - PLUG FOR 1-5/16-12 FLARED JIC FTNGOR 1 TUBE
1.000
25.4
 1-5/16 - 12 16
0.930
23.6
1.500
38.1
0.250
6.4
 2000 400 40
FJP180 Male Flared JIC Plastic Plugs - PLUG FOR 1-1/2-12 FLARED JIC FTNG
-
-
 1-1/2 - 12
0.930
23.6
1.750
44.5
0.250
6.4
 1000 200 20
FJP190 Joint Industry Council Fittings - PLUG FOR 1-5/8-12 FLARED JIC FTNG
1.250
31.8
 1-5/8 - 12 20
0.940
23.9
2.220
56.4
0.340
8.6
 500 100 10
FJP200 Threaded Plastic Flared JIC Plugs - PLUG FOR 1-3/4-12 FLARED JIC FTNG
-
-
 1-3/4 - 12
0.970
24.6
2.310
58.7
0.340
8.6
 500 100 10
FJP280 Threaded Plastic Plugs for Flared JIC Fittings - PLUG FOR 1-7/8-12 FLARED JIC FTNG
1.500
38.1
 1-7/8 - 12 24
1.060
26.9
2.470
62.7
0.380
9.7
 500 100 10
FJP240 Threaded Plastic Cap for Flared JIC Fittings - PLUG FOR 1-7/8-12 FLARED JIC FTNGOR 1-1/2 TUBE
1.500
38.1
 1-7/8 - 12 24
1.150
29.2
2.310
58.7
0.310
7.9
 500 100 10
FJP300 Threaded Plastic Plugs for Flared JIC Fittings - PLUG FOR 2-1/4-12 FLARED JIC FTNGOR 1-3/4 TUBE
1.750
44.5
 2-1/4 - 12
1.310
33.3
2.750
69.9
0.380
9.7
 300 60 6
FJP320 Threaded Plastic Plugs for Flared JIC Fittings - PLUG FOR 2-1/2-12 FLARED JIC FTNG
2.000
50.8
 2-1/2 - 12 32
1.310
33.3
3.090
78.5
0.380
9.7
 300 60 6
Part # Description Tube Size
in
mm
 To Fit STD Thread JIC Fitting Dash Size Length
in
mm
 Flange OD
in
mm
 Flange Thickness
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.



Threaded Plastic Plugs for Flared JIC Fittings - Information

MOCAP Threaded Plastic Plugs are designed for use on Flared JIC fittings. These Threaded Plastic Plugs are knurled for easy use in manual assembly and removal. They can also be used to seal 37° flare fittings without gaskets.
Protects threaded fittings from moisture, dust and damage during production, shipping and storage. Designed to work in low-pressure testing requirements.
Our FJP Series Threaded Plugs are molded in Red polyethylene plastic and sized to fit Flared JIC Fittings from 5/16-24 thru 2-1/2-12 for nominal sized tubes from 1/8 thru 2.

MOCAP stocks Threaded Plastic Plugs for Flared JIC Fittings in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.







RoHS


Diagram
