Square Head Flanged Plugs for NPT Threads

SFPN


Flanged NPT Plugs with Square Head
Square Head Flanged Plugs for NPT Threads

SFPN–Media

Square Head Flanged Plugs for NPT Threads Square Head Flanged Plug for NTP Threads Flanged NPT Blanking Plugs Square Head Blanking Plugs Flanged Plugs for National Pipe Threads Flanged NPT Plugs with Square Head Plastic Flanged Square Head Bolt for NPT Threads Square Head Flanged Threaded Plug Caps Polypropylene Flared Square Head Plugs for NPT Threads Square Head Flanged Plugs for NPT Threads
  • Material: PP (Polypropylene)
  • Stocked Material: PP (Red)
  • Designed to Protect Threads from Dirt, Dust and Moisture During Low-Pressure Testing and In-Plant Handling
  • Flange Allows for Protection of the Outside of Port

Size Chart Flanged NPT Blanking Plugs

SFPN Size Chart

Table View
List View
Part # Description To Fit NPT Stem Height
in
mm
 Threaded Area Length
in
mm
 Flange OD
in
mm
 Head
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
SFPN0125 Square Head Flanged Plugs for NPT Threads - SQ HEAD FLANGED PLUG FOR 1/8-27 NPT THRDS 1/8 - 27
0.190
4.8
0.290
7.4
0.550
14.0
0.280
7.1
 5000 1000 100
SFPN0250 Polypropylene Flared Square Head Plugs for NPT Threads - SQ HEAD FLANGED PLUG FOR 1/4-18 NPT THRDS 1/4 - 18
0.250
6.4
0.350
8.9
0.670
17.0
0.430
10.9
 5000 1000 100
SFPN0375 Square Head Flanged Threaded Plug Caps - SQ HEAD FLANGED PLUG FOR 3/8-18 NPT THRDS 3/8 - 18
0.250
6.4
0.410
10.4
0.800
20.3
0.430
10.9
 2500 500 50
SFPN0500 Plastic Flanged Square Head Bolt for NPT Threads - SQ HEAD FLANGED PLUG FOR 1/2-14 NPT THRDS 1/2 - 14
0.250
6.4
0.470
11.9
0.980
24.9
0.560
14.2
 3000 600 60
SFPN0750 Flanged NPT Plugs with Square Head - SQ HEAD FLANGED PLUG FOR 3/4-14 NPT THRDS 3/4 - 14
0.250
6.4
0.520
13.2
1.240
31.5
0.620
15.7
 2000 400 40
Part # Description To Fit NPT Stem Height
in
mm
 Threaded Area Length
in
mm
 Flange OD
in
mm
 Head
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.



Square Head Flanged Plugs for NPT Threads - Information

MOCAP Square Head Flanged Plugs are designed for use on NPT threads and fittings. The Square Head design allows for easy installation. The Flange design protects the outside of the port, while the plugs keep ports protected during low-pressure testing and in-house processing or handling. These are not intended for permanent applications.
These plugs protect threaded components from moisture, dust and damage during production, shipping and storage, and can also be used as masking during painting and plating. Our SFPN Series Threaded Plugs are molded in Red polypropylene plastic and sized to fit NPT threads from 1/8-27 thru 3/4-14.

MOCAP stocks Square Head Flanged Plugs for NPT Threads in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
