Pull Tab Vinyl Plastic Caps
FPT
Caps with Plastic Grab Tag
View Larger Image
FPT–Media
- Material: Vinyl
- Flexible Yet Durable - Won't Split, Tear or Shred
- Flat / Ergonomic Tab for Easy Removal
- Stretches for a Snug Fit but Won't Split, Tear or Shred
Size Chart Flexible Pull Tab Caps
FPT Size Chart
| Part # | Description | Inside Diameter in mm |
Min Inside Length in mm |
Max Inside Length in mm |
Wall Thickness in mm |
Tab Height in mm |
Stocked Length in |
Box/Mini/Micro QTY |
Buy Online More info |
|---|---|---|---|---|---|---|---|---|---|
| FPT9617 | Pull Tab Vinyl Plastic Caps - .187FPT X ? IL FLAT PULL TAB CAP | 0.187 4.7 |
0.250 6.4 |
1.000 25.4 |
0.038 1.0 |
0.500 12.7 |
- | -- -- -- | |
| FPT9618 | Pull Tag Caps - .215FPT X ? IL FLAT PULL TAB CAP | 0.215 5.5 |
0.250 6.4 |
1.000 25.4 |
0.038 1.0 |
0.500 12.7 |
- | -- -- -- | |
| FPT9619 | Rubber Caps with Pull Tag - .236FPT X ? IL CAP | 0.236 6.0 |
0.250 6.4 |
1.000 25.4 |
0.038 1.0 |
0.500 12.7 |
1 | 5390 1078 106 | |
| FPT9620 | Plastic Pullable Caps - .250FPT X ? IL FLAT PULL TAB CAP | 0.250 6.4 |
0.250 6.4 |
1.000 25.4 |
0.038 1.0 |
0.500 12.7 |
1 | 5225 1045 104 | |
| FPT9406 | Caps with Plastic Grab Tag - .313FPT X ? | 0.313 8.0 |
0.250 6.4 |
1.500 38.1 |
0.038 1.0 |
0.655 16.6 |
1 | 5280 1056 105 | |
| FPT9507 | Round Grab Tab Caps - .343FPT X ? | 0.343 8.7 |
0.250 6.4 |
1.500 38.1 |
0.038 1.0 |
0.695 17.7 |
1 | 5325 1065 106 | |
| FPT9430 | Rubber Caps with Grabbable Tab - .375FPT X ? CAP | 0.375 9.5 |
0.250 6.4 |
1.500 38.1 |
0.055 1.4 |
0.695 17.7 |
1 | 5280 1056 105 | |
| FPT9422 | Flexible Pull Tab Caps - .406FPT - ? | 0.406 10.3 |
0.250 6.4 |
1.500 38.1 |
0.055 1.4 |
0.709 18.0 |
1 | 5280 1056 105 | |
| FPT9431 | PVC Pull Tab Caps - .437FPT X ? | 0.437 11.1 |
0.250 6.4 |
1.500 38.1 |
0.055 1.4 |
0.725 18.4 |
1 | 5355 1071 107 | |
| FPT9435 | Pull Tab Vinyl Plastic Caps - .460FPT X ? CAP | 0.460 11.7 |
0.250 6.4 |
1.500 38.1 |
0.055 1.4 |
0.750 19.1 |
1 | 3840 768 76 | |
| FPT9432 | Pull Tag Caps - .500FPT X ? | 0.500 12.7 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.752 19.1 |
1 | 5040 1008 100 | |
| FPT9433 | Rubber Caps with Pull Tag - .531FPT X ? | 0.531 13.5 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.764 19.4 |
1 | 4320 864 86 | |
| FPT9362 | Plastic Pullable Caps - .562FPT X ? IL Cap | 0.562 14.3 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.613 15.6 |
1 | 2544 509 50 | |
| FPT9429 | Caps with Plastic Grab Tag - .625FPT X ? | 0.625 15.9 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.709 18.0 |
1 | 2700 540 54 | |
| FPT9621 | Round Grab Tab Caps - .655FPT X ? IL FLAT PULL TAB CAP | 0.655 16.6 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.812 20.6 |
1 | 2652 530 53 | |
| FPT9436 | Rubber Caps with Grabbable Tab - .687FPT X ? Std CAP | 0.687 17.4 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.812 20.6 |
1 | 2720 544 54 | |
| FPT9622 | Flexible Pull Tab Caps - .750FPT X ? IL FLAT PULL TAB CAP | 0.750 19.1 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.826 21.0 |
1 | 2100 420 42 | |
| FPT9623 | PVC Pull Tab Caps - .812FPT X ? IL FLAT PULL TAB CAP | 0.812 20.6 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.837 21.3 |
1 | 2100 420 42 | |
| FPT9624 | Pull Tab Vinyl Plastic Caps - .843FPT X ? IL FLAT PULL TAB CAP | 0.843 21.4 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.846 21.5 |
1 | 2240 448 44 | |
| FPT9434 | Pull Tag Caps - .875FPT X ? Std | 0.875 22.2 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.846 21.5 |
1 | 2100 420 42 | |
| FPT9438 | Rubber Caps with Pull Tag - .937FPT X ? Std | 0.937 23.8 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.853 21.7 |
1 | 2080 416 41 | |
| FPT9439 | Plastic Pullable Caps - 1.000FPT X ? | 1.000 25.4 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.858 21.8 |
1 | 1440 288 28 | |
| FPT9625 | Caps with Plastic Grab Tag - 1.062FPT X ? IL FLAT PULL TAB CAP | 1.062 27.0 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.858 21.8 |
1 | 1320 264 26 | |
| FPT9626 | Round Grab Tab Caps - 1.125FPT X ? IL FLAT PULL TAB CAP | 1.125 28.6 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.858 21.8 |
1 | 1360 272 27 | |
| FPT9627 | Rubber Caps with Grabbable Tab - 1.250FPT X ? IL FLAT PULL TAB CAP | 1.250 31.8 |
0.250 6.4 |
1.500 38.1 |
0.060 1.5 |
0.858 21.8 |
1 | 1200 240 24 | |
| Part # | Description | Inside Diameter in mm |
Min Inside Length in mm |
Max Inside Length in mm |
Wall Thickness in mm |
Tab Height in mm |
Stocked Length in |
Box/Mini/Micro QTY |
Buy Online More info |
Legend:
- Add to Cart
- View Price
'D' dimension varies by size. Contact MOCAP Sales for details.
Wall thickness is measured approx. ¼” (6.35mm) from open end. Wall thickness increases slightly towards the closed end of the part
Micropacks are only available for purchase through our online store.
To place an order for this product, click the "buy" button below. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
Pull Tab Vinyl Plastic Caps - Information
MOCAP Pull Tab Vinyl Plastic Caps have an ergonomic design which allow for easy removal from your part. Pull tab plastic caps offer excellent protection from moisture and contaminates. These plastic caps stretch just enough to form for a secure fit and will not fall off during shipment.
Our round vinyl plastic Pull Tab Caps can be produced in various colors, wall thicknesses, hardness durometers and lengths to 1-1/2" (in 1/16" increments). The advantages of the vinyl dip molding process allows MOCAP to offer any of these options with no additional tooling charges.MOCAP stocks Pull Tab Caps in many sizes for immediate shipment or we can manufacture the Pull Tab Caps made-to-order with the fastest lead-times in the industry.
- Flexible Vinyl Plastic for Snug Fit
- Ergonomic Tab for Easy Removal
- Sizes to Fit 3/16" to 1-1/8" Diameters
Masking Applications
MOCAP vinyl plastic pull tab caps are often used as inexpensive and disposable single use masking caps for painting and coating processes under 300°F(149°C). The pull tab end makes removal easy. For higher temperatures, these can be produced in our High Temperature Vinyl.
MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
