Push-in Flange Protectors

MPI


Plastic Push-in Flange Protective Cover
Push-in Flange Protectors

MPI–Media

Push-in Plastic Flange Protectors Push-in Plastic Flange Protector Plastic Flange Covers Push-In Flange Protector Push-in Plastic Flange Protectors Plastic Push-in Flange Protective Cover Plastic Protective Push-in Flange Plugs
  • Material: LDPE (Low Density Polyethylene)
  • Stocked Material: LDPE (Yellow)
  • Designed to Protect Flange Faces from Damage and Debris
  • Flexible Rings Allow for Easy Installation

Size Chart Plastic Flange Covers

MPI Size Chart

Table View
List View
Part # Description To Fit Nominal Pipe Size DIN Diameter
in
mm
Flange OD
in
mm
Length
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
MPI500 Push-in Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 1/2") 1/2” DN 15
0.748
19.0
3.543
90.0
0.591
15.0
1000 200 20
MPI750 Plastic Push-in Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 3/4") 3/4” DN 20
0.945
24.0
3.937
100.0
0.591
15.0
700 140 14
MPI1000 Plastic Push-in Flange Caps - Push-in Plastic Flange Protector (Nominal Pipe Size: 1") 1 ” DN 25
1.181
30.0
4.331
110.0
0.787
20.0
500 100 10
MPI1250 Plastic Protective Push-in Flange Plugs - Push-in Plastic Flange Protector (Nominal Pipe Size: 1-1/4") 1-1/4” DN 32
1.535
39.0
5.354
136.0
0.787
20.0
300 60 6
MPI1500 Plastic Push-in Flange Protective Cover - Push-in Plastic Flange Protector (Nominal Pipe Size: 1-1/2") 1-1/2” DN 40
1.772
45.0
5.748
146.0
0.787
20.0
250 50 5
MPI2000 Push-in Plastic Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 2") 2 ” DN 50
2.205
56.0
6.299
160.0
0.787
20.0
200 40 4
MPI2500 Push-In Flange Protector - Push-in Plastic Flange Protector (Nominal Pipe Size: 2-1/2") 2-1/2” DN 65
2.835
72.0
7.087
180.0
0.787
20.0
200 40 4
MPI3000 Plastic Flange Covers - Push-in Plastic Flange Protector (Nominal Pipe Size: 3") 3 ” DN 80
3.346
85.0
7.717
196.0
0.984
25.0
150 30 3
MPI4000 Push-in Plastic Flange Protector - Push-in Plastic Flange Protector (Nominal Pipe Size: 4") 4 ” DN 100
4.291
109.0
8.504
216.0
0.984
25.0
100 20 2
MPI5000 Push-in Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 5") 5 ” DN 125
5.276
134.0
9.685
246.0
0.984
25.0
75 15 1
MPI6000 Plastic Push-in Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 6") 6 ” DN 150
6.339
161.0
11.023
280.0
1.378
35.0
40 8 1
MPI8000 Plastic Push-in Flange Caps - Push-in Plastic Flange Protector (Nominal Pipe Size: 8") 8 ” DN 200
8.268
210.0
13.228
336.0
1.378
35.0
40 8 1
MPI10000 Plastic Protective Push-in Flange Plugs - Push-in Plastic Flange Protector (Nominal Pipe Size: 10") 10 ” DN 250
10.315
262.0
15.354
390.0
1.575
40.0
28 5 1
MPI12000 Plastic Push-in Flange Protective Cover - Push-in Plastic Flange Protector (Nominal Pipe Size: 12") 12 ” DN 300
12.520
318.0
17.717
450.0
1.890
48.0
20 4 1
Part # Description To Fit Nominal Pipe Size DIN Diameter
in
mm
Flange OD
in
mm
Length
in
mm
Box/Mini/Micro
QTY
Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.



Push-in Flange Protectors - Information

MOCAP Push-In Flange Protectors are designed to fit many different styles and sizes of Flanges, allowing for maximum flexibility. Designed to protect from damage and detritus during transit, handling and storage, our MPI series products are easy to install and remove.

Suitable for both imperial (ANSI) and metric (DIN) flanges to specifications DIN2627 - 2638, 150, BS 5504 and ANSIB16,5.
Our MPI Series Plugs are molded in Yellow polyethylene plastic to fit 1/2" thru 12" nominal sized pipe flanges.

MOCAP stocks Push-in Flange Protectors in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.
