Long Flanged Caps for Straight Threads

 800.633.6775


Long Flanged Caps for Straight Threads

FCSL


Polyethylene Plastic Long Flanged Caps for Standard Threads
Long Flanged Caps for Straight Threads

FCSL–Media

Long Flanged Caps for Straight Threads Plastic Long Flanged Caps for Standard Threads Large Protector Caps Long Flanged Plastic Caps for Standard Straight Threads Flanged Plastic Fittings Polyethylene Plastic Long Flanged Caps for Standard Threads Plastic Long Flanged Caps for Standard Threads Standard Straight Threads - Plastic Long Flanged Caps Long Flanged Plastic Caps for Standard Straight Threads Long Flanged Caps for Straight Threads
  • Material: LDPE (Low Density Polyethylene) (Red)
  • Flanged for Easy Removal
  • Use as Thread Protector or End Cap

Available in the following varieties:

FCS - Flanged Caps for Straight Threads Flanged Plastic Caps for Standard Straight Threads
FCSL - Long Flanged Caps for Straight Threads Long Flanged Caps for Straight Threads
FCM - Flanged Caps for Metric Threads Flanged Plastic Caps for Metric Threads
FCBN - Flanged Caps for BSP and NPT Threads Flanged Plastic Caps for BSP and NPT Threads

Size Chart Large Protector Caps

FCSL Size Chart

Table View
List View
Part # Description To Fit STD Thread Inside Diameter
in
mm
 Flange OD
in
mm
 Inside Length
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
FCSL.313 Long Flanged Caps for Straight Threads - FLANGE CAP FOR 5/16" STR THRDS 1.240" LONG LDPE 5/16
0.308
7.8
0.460
11.7
1.240
31.5
 5000 1000 100
FCSL.375 Long Flanged Plastic Caps for Standard Straight Threads - FLANGE CAP FOR 3/8" STR THRDS 1.240" LONG LDPE 3/8
0.370
9.4
0.520
13.2
1.240
31.5
 5000 1000 100
FCSL.437 Standard Straight Threads - Plastic Long Flanged Caps - FLANGE CAP FOR 7/16" STR THRDS 1.330" LONG LDPE 7/16
0.429
10.9
0.580
14.7
1.330
33.8
 5000 1000 100
FCSL.500 Plastic Long Flanged Caps for Standard Threads - FLANGE CAP FOR 1/2" STR THRDS 1.330" LONG LDPE 1/2
0.490
12.4
0.640
16.3
1.330
33.8
 5000 1000 100
FCSL.563 Polyethylene Plastic Long Flanged Caps for Standard Threads - FLANGE CAP FOR 9/16" STR THRDS 1.410" LONG LDPE 9/16
0.552
14.0
0.700
17.8
1.410
35.8
 5000 1000 100
FCSL.750 Flanged Plastic Fittings - FLANGE CAP FOR 3/4" STR THRDS 1.560" LONG LDPE 3/4
0.739
18.8
0.880
22.4
1.560
39.6
 2500 500 50
FCSL.750L Long Flanged Plastic Caps for Standard Straight Threads - FLANGE CAP FOR 3/4" STR THRDS 2.660" LONG LDPE 3/4
0.739
18.8
0.880
22.4
2.660
67.6
 2000 400 40
FCSL.875 Large Protector Caps - FLANGE CAP FOR 7/8" STR THRDS 1.700" LONG LDPE 7/8
0.861
21.9
1.010
25.7
1.700
43.2
 2500 500 50
FCSL.875L Plastic Long Flanged Caps for Standard Threads - FLANGE CAP FOR 7/8" STR THRDS 2.660" LONG LDPE 7/8
0.861
21.9
1.010
25.7
2.660
67.6
 1500 300 30
FCSL1.000 Long Flanged Caps for Straight Threads - FLANGE CAP FOR 1" STR THRDS 1.800" LONG LDPE 1
0.988
25.1
1.150
29.2
1.800
45.7
 1500 300 30
FCSL1.062 Long Flanged Plastic Caps for Standard Straight Threads - FLANGE CAP FOR 1-1/16" STR THRDS 1.890" LONG LDPE 1-1/16
1.049
26.6
1.190
30.2
1.890
48.0
 1000 200 20
FCSL1.062L Standard Straight Threads - Plastic Long Flanged Caps - FLANGE CAP FOR 1-1/16" STR THRDS 3.000" LONG LDPE 1-1/16
1.049
26.6
1.190
30.2
3.000
76.2
 900 180 18
FCSL1.125 Plastic Long Flanged Caps for Standard Threads - FLANGE CAP FOR 1-1/8" STR THRDS 2.120" LONG LDPE 1-1/8
1.113
28.3
1.250
31.8
2.120
53.8
 1500 300 30
FCSL1.125L Polyethylene Plastic Long Flanged Caps for Standard Threads - FLANGE CAP FOR 1-1/8" STR THRDS 3.100" LONG LDPE 1-1/8
1.113
28.3
1.250
31.8
3.100
78.7
 900 180 18
FCSL1.313 Flanged Plastic Fittings - FLANGE CAP FOR 1-5/16" STR THRDS 1.890" LONG LDPE 1-5/16
1.299
33.0
1.440
36.6
1.890
48.0
 1000 200 20
FCSL1.625 Long Flanged Plastic Caps for Standard Straight Threads - FLANGE CAP FOR 1-5/8" STR THRDS 1.920" LONG LDPE 1-5/8
1.611
40.9
1.760
44.7
1.920
48.8
 500 100 10
FCSL1.875 Large Protector Caps - FLANGE CAP FOR 1-7/8" STR THRDS 1.940" LONG LDPE 1-7/8
1.861
47.3
2.010
51.1
1.940
49.3
 300 60 6
Part # Description To Fit STD Thread Inside Diameter
in
mm
 Flange OD
in
mm
 Inside Length
in
mm
 Box/Mini/Micro
QTY		 Buy Online
More info
Legend:
- Add to Cart - View Price

Micropacks are only available for purchase through our online store.


Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.



Long Flanged Caps for Straight Threads - Information

MOCAP Long Flanged Caps are designed to protect standard straight threads with or without O-rings. Our Flanged caps for standard straight threads are easy to assemble or remove by hand or with automated equipment.
These Flanged Caps feature a longer length than our standard FCS Series flanged caps, adding extra protection for parts with increased thread length. Protects components or fittings from moisture, dust and damage during production, shipping and storage, and can also be used as low-temp masking during painting and plating. Our FCSL Series Caps are molded in Red polyethylene plastic and sized to cap Straight threads from 5/16" thru 1-7/8".

MOCAP stocks Long Flanged Caps for Straight Threads in many sizes for immediate shipment.

MOCAP now offers Micro-Pack and Mini-Pack quantities when less than case quantities are what you really need. To place an order, click the cart icon on the size chart. Or, to get more information about MOCAP products, call 800.633.6775 or use our Contact Request Form to receive information by e-mail.







RoHS


Diagram
MOCAP - Long Flanged Caps for Straight Threads
